Introduction
If the LCD screen on your RCV2 Strapping Machine becomes cracked or unreadable, the good news is that the screen can be replaced without replacing the entire machine.
This article is written for end users and explains the replacement process in a clear and easy-to-follow way. We’ve also included a step-by-step video tutorial to guide you through the installation.
Common LCD Screen Issues
You may need to replace the LCD screen if you notice:
-
A cracked or damaged display
-
Text or numbers that are difficult or impossible to read
If the machine still operates normally, replacing the LCD screen usually resolves the issue.
Before You Begin
⚠️ Please Read Before Starting:
-
Turn off the machine and disconnect it from the power source
-
Perform the replacement on a clean, stable surface
-
This guide is intended for users with basic technical skills
-
If you are not comfortable performing the replacement, please contact our support team
LCD Screen Replacement Overview
Below is a general overview of the replacement process.
For detailed visuals, please watch the video tutorial below.
Step 1: Open the Housing
Remove the three screws securing the housing.
⚠️ The screws are different lengths — please remember their original positions.
Step 2: Remove the Housing Cover
Carefully remove the housing cover and locate the LCD ribbon cable.
Gently disconnect the cable.
Step 3: Remove the Old LCD Screen
Remove the four screws holding the LCD screen in place, then take out the old screen.
Step 4: Install the New LCD Screen
Position the new LCD screen and secure it with the four screws.
Reconnect the ribbon cable firmly.
Step 5: Test the Screen and Buttons
Power on the machine to confirm that the display and buttons work properly.
Step 6: Reassemble the Housing
Once testing is complete, reinstall the housing cover to finish the replacement.
Video Tutorial
🎥 RCV2 LCD Screen Replacement – Step-by-Step Video Guide
This video provides a clear visual demonstration to help ensure a smooth installation.
Need Help or Replacement Parts?
If you need assistance, replacement parts, or have any questions during installation, our support team is here to help.
👉 Contact Rockcub Support for guidance before or during the replacement process.
Email: support@rockcub.com
Final Reminder
This guide is provided to help you understand the replacement process.
If you are unsure about any step, we recommend seeking assistance from a qualified technician.
Thank you for choosing Rockcub.
